The OCB-DNPKL-12TC by OCB is a flagship 12-Megapixel (12MP) bullet camera designed for maximum forensic detail.
Increments of 1
Minimum of 1
Maximum of
0Low stock
0In stock, ready to ship
Sale price
$107.14
-100%
Regular price
Regular price
$107.14
Unit price
per
The OCB-DNPKL-12TC by OCB is a flagship 12-Megapixel (12MP) bullet camera designed for maximum forensic detail.
Sale price
$107.14
Regular price
Regular price
$107.14
Unit price
per
Couldn't load pickup availability
The camera captures video at a 5MP resolution (2592 x 1944), providing 2.5 times the detail of standard 1080p. This higher pixel density is crucial for "forensic" zooming, allowing you to identify faces or clothing patterns more clearly during playback.
Product Features
- High quality imaging with 5MP resolution；
- 1/2.8"Progressive Scan CMOS Sensor;
- Support H.264/H.264+/H.265/H.265+ Compression ;
- Minimum Illumination：0.003 Lux ,Infrared Distance：25m, Warm light:25m；
- Support 120dB;
- Housing: Metal, IP67
Ultra-HD Sensor & Video Performance
Image Sensor: 1/2.8" SONY Starvis Back-illuminated CMOS Sensor
Resolution: 12MP (3864 x 2192 pixels)
Compression: H.265 / H.265+ / H.264 / H.264+ / MJPEG
Min. Illumination: Color: 0.005 Lux @ F1.6; 0 Lux with White Light/IR
Main Stream: 4000*3000 @ 15fps / 3840*2160 @ 25fps
WDR: 120dB (True WDR)
Lens & Illumination
Lens Options: 2.8mm (114° Diagonal) / 4mm (97° Diagonal) / 6mm (60° Diagonal)
Aperture: F1.6 (Auto Control Focus)
Night Vision: Dual Light: IR LEDs (40m) + Warm White LEDs (30m)
Illumination Mode: Smart, Manual, and Timed Full-Color Support
AI & Intelligent Functions
AI Detection: Intrusion, Line Crossing, Loiter, People Gather (Human/Vehicle Based)
Perimeter AI: Enter Area, Leave Area (Human & Vehicle Detection)
Image Features: 3D NR, HLC, BLC, ROI, Corridor Pattern, Privacy Mask (3 Zones)
Connectivity & Interface
Audio: Built-in Mic (Optional Audio I/O or Built-in Speaker)
Storage: Optional External SD Card Slot (Max 512GB)
Network: RJ-45 (10/100Base-T), ONVIF 24.12 (Profile S/T/G/M)
PoE: Internal, IEEE 802.3af Support
General Specifications
Housing: Metal Case, IP67 Rated (Weatherproof)
Dimensions: Ø 96 x 91(H) mm
Weight: 461g
Power Source: DC12V±10%, 700mA / PoE
Working Temp.: -20°C ~ +60°C; Humidity 95% Max
