WI-PS526G (V4) : 24-Port Fast Ethernet PoE Switch with Hi-PoE and Long-Range CCTV Optimization

WI-PS526G (V4) : 24-Port Fast Ethernet PoE Switch with Hi-PoE and Long-Range CCTV Optimization

The WI-PS526G (V4) is a professional-grade PoE switch engineered for large-scale surveillance, access control, and alarm deployments. With 24× PoE ports, 2× Gigabit Combo SFP uplinks, and Hi-PoE 60 W capability, it provides reliable power distribution, long-distance transmission, and stability required for modern security networks.

 Product Features

• 24× 10/100 Mbps PoE ports plus 2× 1 Gbps Combo SFP uplinks for flexible backbone connectivity.
• Hi-PoE 60 W power support on ports 1–2, ideal for high-consumption PTZ cameras or specialized devices.
• IEEE 802.3af/at 30 W PoE on ports 3–24, ensuring compatibility with IP cameras, access control panels, and APs.
• PoE watchdog functionality for automatic recovery of unresponsive devices.
• Smart DIP switch modes, including:
– Extend Mode (250 m) for long-distance PoE CCTV runs.
– VLAN Mode for port isolation and enhanced security.
– CCTV Mode with QoS prioritization for stable video transmission.
• Total PoE power budget up to 258 W, optimized for multi-camera installations.
• Plug-and-play design, no configuration required for rapid field deployment.
• High-performance switching ensures stable operation under CCTV-heavy traffic.

The WI-PS526G (V4) combines high PoE power, long-distance reach, Hi-PoE capability, and CCTV-focused automation—making it an ideal switch for complex professional security deployments.
